FD110K - Pneumatic Crimping Press - Output Force: 1.8Tons
Original price
$699.00
-
Original price
$699.00
Original price
$699.00
$699.00
-
$699.00
Current price
$699.00
SKU FD110K
Availability:
in stock, ready to be shipped
FD110K Pneumatic Crimping Press - 1.8 Ton Output Force
None
Click here to view instruction manual:
- "Plug 'n Play" Pneumatic Press with interchangeable crimping dies. Quick and easy to install, easier to operate
- Die sets can be changed in seconds
-
Crimping Range:
- Wire Ferrules: 0.25mm2 to 50.00mm2 (24 to 1AWG)
- Insulated Terminals and other connectors: 0.14mm2 to 16.00mm2 (26 to 6AWG).
- Non-Insulated Terminals and other connectors: 0.34mm2 to 10.00mm2 (22 to 8AWG).
- Crimping Length: 8mm - (For longer ferrules, pass through and crimp twice)
- Output Force: 1.8 Tons (17.6kN | 3,968 pound-force)
- Recommended Air Pressure: 80-100psi
- Max Air Pressure: 7 BAR
- Crimping Press Dimensions: 275x128x145mm (10.8x5.0x5.7")
- Weight: 8 Kilos (17.6 lbs)
For all applicable dies, click below:
Cross References
Cross Reference Parts:None
Documents
Click here to view warranty information:Click here to view instruction manual:
